The Multi-station Plastic Thermoforming Machine is an integrated machinery that enables users to create a wide variety of plastic products.
Integrated Design,R&D, Produce, Sales and Service.
High Standard Quality.
Easy Operation.
Service
Our Multi-Station Plastic Thermoforming Machine is high levels of precision in the design and manufacture of plastic products.
This machine can accommodate a range of materials and product sizes.
The machine is capable of producing plastic products at a high rate of speed.
Our machine is energy-efficient, which means that it can help businesses reduce their running costs and minimize their impact on the environment.
Automatic Multi-Station Plastic Thermoforming Machine
Machine model : ZDL-7085
Body size: appr.11,000*2,200*2,700mm
Forming size: 700*840mm
Forming method: Positive and negative pressure
Forming servo: Upper 4.5KW / Lower 4.5KW
Punching servo: Upper 7.5KW / Lower 5.5KW
Pulling servo: 4.5KW
Mold opening stroke: Upper 150mm / Lower 150mm
Die stroke: Upper 150mm / Lower 150mm
Security protection: Sliding door and light sensor protection
Chiller: 10P ice water machine
Pulling beam: Steel(hardness 58)
Vacuum pump: 100m3
Robot arm: Lateral/download
Feeding rack: By cylinder pull
Beam alignment: By PLC and Manual button
Electric source: 380V/220V/50Hz
Applicable sheets: PET/PS/ABS/PVC/PE
Machine weight: appr.11T
